Diodes Incorporated BSS138DW-7-F Dual N-Channel MOSFET SOT363
- Brand
- Diodes Incorporated
- Model
- BSS138DW-7-F
- GEARWELL SKU
- GWP-000023483
- Category
- Industrial Components
Key specifications
- Ciss typ
- 50 pF
- Polarity
- N+N (dual)
- Package / packing
- SOT363, 3000/tape & reel
- RDS(on) max @ VGS 10 V
- 3500 mΩ
- Drain current |ID| @25 °C
- 0.2 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Diodes Incorporated BSS138DW-7-F Dual N-Channel MOSFET SOT363 |
|---|---|
| Brand | Diodes Incorporated |
| Model | BSS138DW-7-F |
| Category | Industrial Components |
| Ciss typ | 50 pF |
| Polarity | N+N (dual) |
| Package / packing | SOT363, 3000/tape & reel |
| RDS(on) max @ VGS 10 V | 3500 mΩ |
| Drain current |ID| @25 °C | 0.2 A |
| Power dissipation @25 °C | 0.2 W |
| Gate-source voltage |VGS| | ±20 V |
| Drain-source voltage |VDS| | 50 V |
| Gate threshold |VGS(th)| max | 1.5 V |
