Digital Power CPCI-AC-3U-200 CPCI 3U 200 W CompactPCI Power Supply
- Brand
- Digital Power
- Model
- CPCI-AC-3U-200
- GEARWELL SKU
- GWP-000033737
- Category
- Power Supplies
Key specifications
- Input
- 90-264 VAC, 47-63 Hz
- Outputs
- +5 V/25 A, +3.3 V/35 A, +12 V/3 A, -12 V/0.5 A
- Evidence
- Digital Power Corporation CPCI 3U Series data sheet (hosted at docs.rs-online.com)
- Standard
- PICMG 2.11, 3U CompactPCI
- Hold-up time
- 16 ms minimum (full load)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Digital Power CPCI-AC-3U-200 CPCI 3U 200 W CompactPCI Power Supply |
|---|---|
| Brand | Digital Power |
| Model | CPCI-AC-3U-200 |
| Category | Power Supplies |
| Input | 90-264 VAC, 47-63 Hz |
| Outputs | +5 V/25 A, +3.3 V/35 A, +12 V/3 A, -12 V/0.5 A |
| Evidence | Digital Power Corporation CPCI 3U Series data sheet (hosted at docs.rs-online.com) |
| Standard | PICMG 2.11, 3U CompactPCI |
| Hold-up time | 16 ms minimum (full load) |
| Output power | 200 W |
| Safety approvals | UL/cUL60950, EN60950, CE Mark (LVD) |
| Code as collected | AC-3U-200 (seller title: Digital Power CPCI AC-3U-200) |
| Efficiency (typical) | 79-81 % |
| Operating temperature | -5 to +55 °C (derate 2.5 %/°C up to +71 °C) |
