DELTA ECMA-LA1855S3 ECMA AC Servo Motor

Key specifications

Max. torque: 87.53 N-m
Model code: L: 400 V / 1,500 rpm; A: absolute encoder (single cycle 17-bit, multi-cycle 16-bit); 18: 180 mm; 55: 5.5 kW; S: keyway with fixed screw holes, with brake, with oil seal; 3: specific shaft diameter 42 mm
Rated power: 5.5 kW
Rated torque: 35.0 N-m
Rated current: 22.37 A

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	DELTA ECMA-LA1855S3 ECMA AC Servo Motor
Brand	DELTA
Model	ECMA-LA1855S3
Category	Servo Systems
Max. torque	87.53 N-m
Model code	L: 400 V / 1,500 rpm; A: absolute encoder (single cycle 17-bit, multi-cycle 16-bit); 18: 180 mm; 55: 5.5 kW; S: keyway with fixed screw holes, with brake, with oil seal; 3: specific shaft diameter 42 mm
Rated power	5.5 kW
Rated torque	35.0 N-m
Rated current	22.37 A
Weight (with brake)	36 kg
Rated speed / max. speed	1500 / 3000 r/min
Max. instantaneous current	56.0 A
