DELTA ECMA-L11313RS ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-L11313RS
- GEARWELL SKU
- GWP-000029818
- Category
- Servo Systems
Key specifications
- Model code
- L=400V/1500r/min, 1=20-bit incremental, 13=130mm, 13=1.3kW, R=keyway with screw hole, no brake, with oil seal, S=standard shaft
- Rated speed
- 1500 r/min
- Rated torque
- 8.34 N-m
- Maximum speed
- 3000 r/min
- Rated current
- 5.02 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-L11313RS ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-L11313RS |
| Category | Servo Systems |
| Model code | L=400V/1500r/min, 1=20-bit incremental, 13=130mm, 13=1.3kW, R=keyway with screw hole, no brake, with oil seal, S=standard shaft |
| Rated speed | 1500 r/min |
| Rated torque | 8.34 N-m |
| Maximum speed | 3000 r/min |
| Rated current | 5.02 A |
| Maximum torque | 23.3 N-m |
| Maximum current | 15 A |
| Rated output power | 1.3 kW |
