DELTA ECMA-G21309SS ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-G21309SS
- GEARWELL SKU
- GWP-000029816
- Category
- Servo Systems
Key specifications
- Model code
- G=220V/1000r/min, 2=17-bit incremental encoder, 13=130mm, 09=900W, S=keyway with screw hole, brake and oil seal, S=standard shaft
- Rated speed
- 1000 r/min
- Rated torque
- 8.59 N-m
- Maximum speed
- 2000 r/min
- Rated current
- 7.5 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-G21309SS ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-G21309SS |
| Category | Servo Systems |
| Model code | G=220V/1000r/min, 2=17-bit incremental encoder, 13=130mm, 09=900W, S=keyway with screw hole, brake and oil seal, S=standard shaft |
| Rated speed | 1000 r/min |
| Rated torque | 8.59 N-m |
| Maximum speed | 2000 r/min |
| Rated current | 7.5 A |
| Maximum torque | 21.48 N-m |
| Maximum current | 22.5 A |
| Rated output power | 0.9 kW |
