DELTA ECMA-F11313SS ECMA AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-F11313SS
- GEARWELL SKU
- GWP-000029813
- Category
- Servo Systems
Key specifications
- Max. torque
- 23.3 N-m
- Model code
- F: 220 V / 1,500 rpm; 1: incremental 20-bit encoder; 13: 130 mm; 13: 1.3 kW; S: keyway with fixed screw holes, with brake, with oil seal; S: standard shaft diameter
- Rated power
- 1.3 kW
- Rated torque
- 8.34 N-m
- Rated current
- 12.6 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-F11313SS ECMA AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-F11313SS |
| Category | Servo Systems |
| Max. torque | 23.3 N-m |
| Model code | F: 220 V / 1,500 rpm; 1: incremental 20-bit encoder; 13: 130 mm; 13: 1.3 kW; S: keyway with fixed screw holes, with brake, with oil seal; S: standard shaft diameter |
| Rated power | 1.3 kW |
| Rated torque | 8.34 N-m |
| Rated current | 12.6 A |
| Weight (with brake) | 10.8 kg |
| Rated speed / max. speed | 1500 / 3000 r/min |
| Max. instantaneous current | 38.6 A |
