DELTA ECMA-C10907SS ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-C10907SS
- GEARWELL SKU
- GWP-000029804
- Category
- Servo Systems
Key specifications
- Model code
- C=220V/3000r/min, 1=20-bit incremental encoder, 09=86mm frame, 07=750W, S=keyway with screw hole, brake and oil seal, S=standard shaft
- Rated speed
- 3000 r/min
- Rated torque
- 2.39 N-m
- Maximum speed
- 3000 r/min
- Rated current
- 3.66 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-C10907SS ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-C10907SS |
| Category | Servo Systems |
| Model code | C=220V/3000r/min, 1=20-bit incremental encoder, 09=86mm frame, 07=750W, S=keyway with screw hole, brake and oil seal, S=standard shaft |
| Rated speed | 3000 r/min |
| Rated torque | 2.39 N-m |
| Maximum speed | 3000 r/min |
| Rated current | 3.66 A |
| Maximum torque | 7.14 N-m |
| Maximum current | 11 A |
| Rated output power | 0.75 kW |
