DELIXI CDS9-D AC380V 200-300A CDS9 Motor Protector
- Brand
- DELIXI
- Model
- CDS9-D AC380V 200-300A
- GEARWELL SKU
- GWP-000021152
- Category
- Contactors & Starters
Key specifications
- Standard
- GB/T 14048.4
- Trip class
- 10A
- Seller code
- CDS9D2BA3BA380
- Type designation
- CDS9-D
- Current transformer
- external CT (x/5 A) for ranges above 200 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDS9-D AC380V 200-300A CDS9 Motor Protector |
|---|---|
| Brand | DELIXI |
| Model | CDS9-D AC380V 200-300A |
| Category | Contactors & Starters |
| Standard | GB/T 14048.4 |
| Trip class | 10A |
| Seller code | CDS9D2BA3BA380 |
| Type designation | CDS9-D |
| Current transformer | external CT (x/5 A) for ranges above 200 A |
| Protection functions | phase loss, overload, locked rotor, three-phase unbalance, under-voltage, leakage, start timeout |
| Setting current range | 200-300 A |
| Rated operational voltage Ue | 380 V AC |
| Rated control supply voltage Us | 380V AC |
