DELIXI CDS36-2L/H 2.4A AC380V CDS36 Electromagnetic Starter
- Brand
- DELIXI
- Model
- CDS36-2L/H 2.4A AC380V
- GEARWELL SKU
- GWP-000021144
- Category
- Contactors & Starters
Key specifications
- Operation
- with push buttons (L), non-reversing (H)
- Seller code
- CDS362LH2X4A380V
- Contactor fitted
- CDC10-10
- Type designation
- CDS36-2L/H
- Control (coil) voltage
- 380V AC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDS36-2L/H 2.4A AC380V CDS36 Electromagnetic Starter |
|---|---|
| Brand | DELIXI |
| Model | CDS36-2L/H 2.4A AC380V |
| Category | Contactors & Starters |
| Operation | with push buttons (L), non-reversing (H) |
| Seller code | CDS362LH2X4A380V |
| Contactor fitted | CDC10-10 |
| Type designation | CDS36-2L/H |
| Control (coil) voltage | 380V AC |
| Thermal overload relay fitted | JR36-20 |
| Thermal setting current range | 1.5-2.4 A |
| Overall dimensions (non-reversing, max.) | 206 x 118 x 119 mm |
| Max. controllable motor power (frame CDS36-2) | 4 kW |
