DATAKOM D-500 Advanced Genset Controller
- Brand
- DATAKOM
- Model
- D-500
- GEARWELL SKU
- GWP-000024961
- Category
- PLCs & I/O
Key specifications
- Display
- 2.9 in, 128 x 64 pixels
- Functions
- AMF, ATS (uninterrupted transfer), remote/manual start, engine controller
- Communication
- Ethernet 10/100, USB host & device, RS-485, RS-232, J1939 CANBUS, Modbus RTU & TCP, SNMP
- DC supply range
- 8.0 to 36.0 VDC
- Contactor outputs
- 16 A @ 250 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DATAKOM D-500 Advanced Genset Controller |
|---|---|
| Brand | DATAKOM |
| Model | D-500 |
| Category | PLCs & I/O |
| Display | 2.9 in, 128 x 64 pixels |
| Functions | AMF, ATS (uninterrupted transfer), remote/manual start, engine controller |
| Communication | Ethernet 10/100, USB host & device, RS-485, RS-232, J1939 CANBUS, Modbus RTU & TCP, SNMP |
| DC supply range | 8.0 to 36.0 VDC |
| Contactor outputs | 16 A @ 250 V |
| Dimensions (W x H x D) | 200 x 148 x 46 mm |
| Operating temperature | -20 to 70 °C |
| Configurable inputs / outputs | 8 digital inputs, 8 digital outputs (each expandable to 40), 4 analog inputs |
