Control Techniques UNI2401-R Unidrive Size 2 AC Drive 400V 5.5kW

Key specifications

Series: Unidrive (classic)
Frame size: 2
Code suffix "-R": as collected; not listed in the official model-number table
Nominal rating: 5.5 / 7.5 kW / hp
Supply voltage: 380-480 V +/-10% three-phase V

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Control Techniques UNI2401-R Unidrive Size 2 AC Drive 400V 5.5kW
Brand	Control Techniques
Model	UNI2401-R
Category	Variable Frequency Drives
Series	Unidrive (classic)
Frame size	2
Code suffix "-R"	as collected; not listed in the official model-number table
Nominal rating	5.5 / 7.5 kW / hp
Supply voltage	380-480 V +/-10% three-phase V
Operating modes	Open loop / closed loop vector / servo / regen
Typical input current	13.0 A
Output current (40 C, 3 kHz)	12 A
