Control Techniques DST1204 Digitax ST Servo Drive
- Brand
- Control Techniques
- Model
- DST1204
- GEARWELL SKU
- GWP-000033621
- Category
- Servo Systems
Key specifications
- Drive family
- Digitax ST (DST), frame size 1
- Line voltage
- 200-240 V AC
- Ingress protection
- IP20
- Switching frequency
- 6 - 12 (selectable) kHz
- Peak output current (3-phase)
- 22.8 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Control Techniques DST1204 Digitax ST Servo Drive |
|---|---|
| Brand | Control Techniques |
| Model | DST1204 |
| Category | Servo Systems |
| Drive family | Digitax ST (DST), frame size 1 |
| Line voltage | 200-240 V AC |
| Ingress protection | IP20 |
| Switching frequency | 6 - 12 (selectable) kHz |
| Peak output current (3-phase) | 22.8 A |
| Continuous output current (3-phase) | 7.6 A |
| Variant (order code digit 8) options | B Base / E EtherCAT / I Indexer / P Plus / Z EZMotion (specify on order) |
| Continuous / peak output current (1-phase) | 4.7 / 9.4 A |
