CHINT NXU-I+II/F 12.5/275 1P Surge Protective Device
- Brand
- CHINT
- Model
- NXU-I+II/F 12.5/275 1P
- GEARWELL SKU
- GWP-000009562
- Category
- Circuit Protection
Key specifications
- Test class
- I+II
- Number of poles
- 1P
- Remote signal contact
- Yes (/F version)
- Voltage protection level (Up)
- 1.5 kV
- Nominal discharge current In (8/20 us)
- 25 kA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CHINT NXU-I+II/F 12.5/275 1P Surge Protective Device |
|---|---|
| Brand | CHINT |
| Model | NXU-I+II/F 12.5/275 1P |
| Category | Circuit Protection |
| Test class | I+II |
| Number of poles | 1P |
| Remote signal contact | Yes (/F version) |
| Voltage protection level (Up) | 1.5 kV |
| Nominal discharge current In (8/20 us) | 25 kA |
| Maximum discharge current Imax (8/20 us) | 50 kA |
| Maximum impulse current Iimp (10/350 us) | 12.5 kA |
| Maximum continuous operating voltage (Uc) | 275 V AC |
