CHENYING CDB-1 Volumetric Distributor 1 Outlets
- Brand
- CHENYING
- Model
- CDB-1
- GEARWELL SKU
- GWP-000012013
- Category
- Lubrication Parts
Key specifications
- A(mm)
- 45
- B(mm)
- 28
- N.W.(g)
- 133
- Series
- CDB Volumetric Distributor
- Inlet Bore
- Ø6(M10xP1.0)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CHENYING CDB-1 Volumetric Distributor 1 Outlets |
|---|---|
| Brand | CHENYING |
| Model | CDB-1 |
| Category | Lubrication Parts |
| A(mm) | 45 |
| B(mm) | 28 |
| N.W.(g) | 133 |
| Series | CDB Volumetric Distributor |
| Inlet Bore | Ø6(M10xP1.0) |
| Outlet Num. | 1 |
| Outlet Bore | Ø4 (M8xP1.0) |
| Outlet Number | 1 Outlets |
| Suitable Viscosity | Oil 32~90cSt@40℃ |
| Outlet Adapter Type | Compression Bushing & Sleeve |
| Discharge Volume options | All 0.1cc / All 0.2cc / All 0.3cc / All 0.4cc / All 0.5cc / All 0.5cc+Sensor Switch / All 0.1cc+Proximity SW / All 0.2cc+Proximity SW / All 0.3cc+Proximity SW / All 0.4cc+Proximity SW / All 0.5cc+Proximity SW / Special Request (Please specify the fittings you need in remarks.) (specify on order) |
| Operating Pressure Range | 8~30kgf/cm² |
| Left Side Inlet Fitting options | φ6 Compression Bushing & Sleeve / Closure Plug / Without Fittings / Special Request (Please specify what you need in remarks.) (specify on order) |
| Right Side Inlet Fitting options | φ6 Compression Bushing & Sleeve / Closure Plug / Without Fittings / Special Request (Please specify what you need in remarks.) (specify on order) |
| Discharge Volume/Stroke (Volume Marking) | 0.1cc (1) 0.2cc (2) 0.3cc (3) 0.4cc (4) 0.5cc (5) |
