CHENYING CCB-1 Large Volumetric Distributor 1 Outlets
- Brand
- CHENYING
- Model
- CCB-1
- GEARWELL SKU
- GWP-000012005
- Category
- Lubrication Parts
Key specifications
- N.W.(g)
- 113
- Series
- CCB Large Volumetric Distributor
- Inlet Bore
- Outer Thread PT1/4
- Outlet Num.
- 1
- Outlet Bore
- Ø4 (M8xP1.0)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CHENYING CCB-1 Large Volumetric Distributor 1 Outlets |
|---|---|
| Brand | CHENYING |
| Model | CCB-1 |
| Category | Lubrication Parts |
| N.W.(g) | 113 |
| Series | CCB Large Volumetric Distributor |
| Inlet Bore | Outer Thread PT1/4 |
| Outlet Num. | 1 |
| Outlet Bore | Ø4 (M8xP1.0) |
| Outlet Number | 1 Outlets |
| Suitable Viscosity | Oil 32~90cSt@40℃ |
| Outlet Adapter Type | Compression Bushing & Sleeve |
| Discharge Volume options | All 1.0cc / All 1.5cc / Special Request (Please specify what you need in remarks.) (specify on order) |
| Operating Pressure Range | 8~30kgf/cm² |
| Left Side Inlet Fitting options | φ6 Straight Adapter with Compression Bushing and Sleeve / φ8 Straight Adapter with Compression Bushing and Sleeve / Closure Plug / Without Fittings / Special Request (Please specify what you need in remarks.) / Except for CCB-1,others all need to provide the order code for inlet fittings. (specify on order) |
| Right Side Inlet Fitting options | φ6 Straight Adapter with Compression Bushing and Sleeve / φ8 Straight Adapter with Compression Bushing and Sleeve / Closure Plug / Without Fittings / Special Request (Please specify what you need in remarks.) / Except for CCB-1,others all need to provide the order code for inlet fittings. (specify on order) |
| Discharge Volume/Stroke (Volume Marking) | 1.0cc (2 Grooves) 1.5cc (3 Grooves) |
