BUSSMANN 170M6409 550 A 690 V AC aR High-Speed Fuse
- Brand
- BUSSMANN
- Model
- 170M6409
- GEARWELL SKU
- GWP-000001149
- Category
- Industrial Automation Parts
Key specifications
- Fuse size
- 3
- Fuse status indicator
- B-type visual indicator (top fuse status indicator)
- Power loss at rated current (manufacturer sources)
- 100 W
- Pre-arc I²t
- 19500 A²s
- Clearing I²t at 660 V AC (Eaton catalogue)
- 135000 A²s
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BUSSMANN 170M6409 550 A 690 V AC aR High-Speed Fuse |
|---|---|
| Brand | BUSSMANN |
| Model | 170M6409 |
| Category | Industrial Automation Parts |
| Fuse size | 3 |
| Fuse status indicator | B-type visual indicator (top fuse status indicator) |
| Power loss at rated current (manufacturer sources) | 100 W |
| Pre-arc I²t | 19500 A²s |
| Clearing I²t at 660 V AC (Eaton catalogue) | 135000 A²s |
| Contact style | Square body, flush end contact |
| Rated current | 550 A |
| Rated AC voltage by standard | 690 V AC (IEC); 700 V AC (UL) |
| Mounting thread | M12 |
| Fuse operating class | aR |
| AC breaking capacity | 200 kA AC (RMS symmetrical) |
