BOURDON TSFE100-231.162.12T.15.8001/737C TSFE 100 Thermometer
- Brand
- BOURDON
- Model
- TSFE100-231.162.12T.15.8001/737C
- GEARWELL SKU
- GWP-000033604
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- TSFE 100
- Contacts
- Mechanical or inductive
- Capillary
- 0.5 … 30 m, stainless steel 1.4541 / AISI 321
- Nominal size
- 100 mm
- Accuracy (EN 13190)
- Class 1
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BOURDON TSFE100-231.162.12T.15.8001/737C TSFE 100 Thermometer |
|---|---|
| Brand | BOURDON |
| Model | TSFE100-231.162.12T.15.8001/737C |
| Category | Pressure, Flow & Temperature |
| Series | TSFE 100 |
| Contacts | Mechanical or inductive |
| Capillary | 0.5 … 30 m, stainless steel 1.4541 / AISI 321 |
| Nominal size | 100 mm |
| Accuracy (EN 13190) | Class 1 |
| Temperature range (series) | -200 … +800 °C |
| Code suffix / open positions | "TSFE100-231.162.12T.15.8001/737C" as collected; positions not verified against the official ordering key (specify on order) |
| Protection rating (EN 60529) | IP65 |
