BAUMER PT20S-G500.1101312.2110000.0150 PT20S Temperature Sensor
- Brand
- BAUMER
- Model
- PT20S-G500.1101312.2110000.0150
- GEARWELL SKU
- GWP-000021909
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 4 ... 20 mA 2-wire / PNP / NPN / push-pull (by version)
- Safety approval
- cULus listed, E527512
- Max. output error
- typ. ≤ 0.06% FSR @ 25 °C
- Type designation
- PT20S-G500.1101312.2110000.0150
- Code group "1101312"
- as collected; official listed variants use 1A01322
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER PT20S-G500.1101312.2110000.0150 PT20S Temperature Sensor |
|---|---|
| Brand | BAUMER |
| Model | PT20S-G500.1101312.2110000.0150 |
| Category | Pressure, Flow & Temperature |
| Output | 4 ... 20 mA 2-wire / PNP / NPN / push-pull (by version) |
| Safety approval | cULus listed, E527512 |
| Max. output error | typ. ≤ 0.06% FSR @ 25 °C |
| Type designation | PT20S-G500.1101312.2110000.0150 |
| Code group "1101312" | as collected; official listed variants use 1A01322 |
| Measuring principle | Pt100 (EN 60751) with integrated transmitter |
| Sensor tube material | AISI 316L (1.4404) |
| Closest official variant | PT20S-G500.1A01322.2110000.0050 (art. 11259378) |
| Surface roughness wetted parts | Ra ≤ 0.8 µm |
