BAUMER AFI4-5630.4002.0110 CombiLyz AFI4 Conductivity Sensor
- Brand
- BAUMER
- Model
- AFI4-5630.4002.0110
- GEARWELL SKU
- GWP-000021779
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 2 x 4...20 mA
- Display
- With display, with activated relays
- Housing
- Bottom process connection
- Configuration
- No configuration
- Article number
- 11129608
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER AFI4-5630.4002.0110 CombiLyz AFI4 Conductivity Sensor |
|---|---|
| Brand | BAUMER |
| Model | AFI4-5630.4002.0110 |
| Category | Pressure, Flow & Temperature |
| Output | 2 x 4...20 mA |
| Display | With display, with activated relays |
| Housing | Bottom process connection |
| Configuration | No configuration |
| Article number | 11129608 |
| Type designation | AFI4-5630.4002.0110 |
| Process connection | G 1 A hygienic, PEEK, length 37 mm (A04) |
| Approvals / calibration | 3-A / EHEDG; No calibration certificate |
| Electrical connection | 2 x M12-A, 4-pin, Stainless steel, AISI 304 (1.4301) |
| Conductivity measuring span | 500 µS/cm … 1000 mS/cm (14 selectable ranges) |
| Process temperature / pressure | -20 … 140 °C permanent; ≤ 25 bar |
