BAUMER 8141-331.0500 8141 Pt100 Cable Temperature Sensor
- Brand
- BAUMER
- Model
- 8141-331.0500
- GEARWELL SKU
- GWP-000022840
- Category
- Pressure, Flow & Temperature
Key specifications
- Output type
- 1 x Pt100, 4-wire
- Cable length
- 500 cm
- Sensor length
- 46 mm
- Article number
- 10319424
- Process pressure
- ≤ 25 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER 8141-331.0500 8141 Pt100 Cable Temperature Sensor |
|---|---|
| Brand | BAUMER |
| Model | 8141-331.0500 |
| Category | Pressure, Flow & Temperature |
| Output type | 1 x Pt100, 4-wire |
| Cable length | 500 cm |
| Sensor length | 46 mm |
| Article number | 10319424 |
| Process pressure | ≤ 25 bar |
| Type designation | 8141-331.0500 |
| Code as collected | [待拆] Baumer 堡盟 8141-331.0500 过程传感器 温度测量 |
| Process temperature | -50 … 205 °C |
| Sensor tube material | AISI 316L (1.4404) |
| Cable sheath material | High-flexible silicone |
| Thermal response time, T50 | 8 s |
| Degree of protection (EN 60529) | IP 65 |
| Pt100 accuracy class (EN 60751) | 1/1 B ± (0.3 + 0.005 × t)°C |
