BAUMER 11200090 OM70-L0600.HV0350.VI Laser Distance Sensor
- Brand
- BAUMER
- Model
- 11200090
- GEARWELL SKU
- GWP-000020584
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Resolution
- 3 … 24 µm
- Light source
- Pulsed red laser diode, 660 nm, laser class 2
- Output signal
- 4 … 20 mA / 0 … 10 VDC, RS485
- Article number
- 11200090
- Protection class
- IP 67
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER 11200090 OM70-L0600.HV0350.VI Laser Distance Sensor |
|---|---|
| Brand | BAUMER |
| Model | 11200090 |
| Category | Proximity & Photoelectric Sensors |
| Resolution | 3 … 24 µm |
| Light source | Pulsed red laser diode, 660 nm, laser class 2 |
| Output signal | 4 … 20 mA / 0 … 10 VDC, RS485 |
| Article number | 11200090 |
| Protection class | IP 67 |
| Type designation | OM70-L0600.HV0350.VI |
| Measuring range Mr | 500 mm |
| Measuring frequency | 2500 Hz |
| Measuring distance Sd | 100 … 600 mm |
| Voltage supply range +Vs | 15 … 28 VDC |
