BAUMER 11165812 VCXU-31M CX Series USB 3.0 Industrial Camera
- Brand
- BAUMER
- Model
- 11165812
- GEARWELL SKU
- GWP-000020570
- Category
- Machine Safety & Vision
Key specifications
- Sensor
- Sony IMX252, 1/1.8″ CMOS
- Lens mount
- C-mount
- Pixel size
- 3.45 × 3.45 µm
- Resolution
- 2048 × 1536 px
- Shutter type
- Global shutter
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER 11165812 VCXU-31M CX Series USB 3.0 Industrial Camera |
|---|---|
| Brand | BAUMER |
| Model | 11165812 |
| Category | Machine Safety & Vision |
| Sensor | Sony IMX252, 1/1.8″ CMOS |
| Lens mount | C-mount |
| Pixel size | 3.45 × 3.45 µm |
| Resolution | 2048 × 1536 px |
| Shutter type | Global shutter |
| Article number | 11165812 |
| Data interface | USB 3.0 (Micro B) |
| Frame rate max. | 117 fps |
| Dimensions (W × H × D) | 29 × 29 × 38 mm |
| Protection class | IP 40 (with lens and cable) |
| Type designation | VCXU-31M |
| Process interface | M8 / 8 pins |
