BALLUFF BTS0002 BTS M30E0-UUI-H0001-S04G Infrared Temperature Sensor
- Brand
- BALLUFF
- Model
- BTS0002
- GEARWELL SKU
- GWP-000017047
- Category
- Pressure, Flow & Temperature
Key specifications
- Dimension
- Ø 30 x 190 mm
- Connection
- M12x1-Male, 4-pin
- Order code
- BTS0002
- Wave length
- 1200…1700 nm
- Repeatability
- ±1 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BALLUFF BTS0002 BTS M30E0-UUI-H0001-S04G Infrared Temperature Sensor |
|---|---|
| Brand | BALLUFF |
| Model | BTS0002 |
| Category | Pressure, Flow & Temperature |
| Dimension | Ø 30 x 190 mm |
| Connection | M12x1-Male, 4-pin |
| Order code | BTS0002 |
| Wave length | 1200…1700 nm |
| Repeatability | ±1 °C |
| Distance ratio | 50:1 |
| Measuring range | 250...1250 °C |
| Type designation | BTS M30E0-UUI-H0001-S04G |
| Code as collected | BTS0002 |
| Operating voltage Ub | 10...30 VDC |
| Temperature resolution | 1 °C, 1 °F, 1 % |
