B&R 8V1090.00-2 ACOPOS Servo Drive
- Brand
- B&R
- Model
- 8V1090.00-2
- GEARWELL SKU
- GWP-000017700
- Category
- Servo Systems
Key specifications
- Power
- 4 kW
- Weight
- approx. 4.4 kg
- Altitude
- ≤ 2000 m
- Main supply
- 3-phase 400-480 VAC (±10%)
- Rated current
- 8.8 (continuous) / 24 (peak) A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | B&R 8V1090.00-2 ACOPOS Servo Drive |
|---|---|
| Brand | B&R |
| Model | 8V1090.00-2 |
| Category | Servo Systems |
| Power | 4 kW |
| Weight | approx. 4.4 kg |
| Altitude | ≤ 2000 m |
| Main supply | 3-phase 400-480 VAC (±10%) |
| Rated current | 8.8 (continuous) / 24 (peak) A |
| Control supply | 24 VDC ±2 V |
| Output frequency | max. 600 Hz |
| Protection rating | IP20 |
| Specification note | Specifications from supplier data; please verify against the nameplate before ordering. |
| Dimensions (W x H x D) | 70.5 x 375 x 235.5 mm |
| Operating temperature | 5 to 40 °C |
