B&R 2AO300.6 System 2010 Analog Output Module
- Brand
- B&R
- Model
- 2AO300.6
- GEARWELL SKU
- GWP-000025496
- Category
- PLCs & I/O
Key specifications
- Evidence
- B&R ControlSystems Overview Catalog 12/99, p.250 (hosted at rgbautomatyka.pl)
- Isolation
- output-PCC yes; output-output no
- Module ID
- AO300
- Resolution
- 12 bit
- Module rack
- BP200, BP201, BP210
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | B&R 2AO300.6 System 2010 Analog Output Module |
|---|---|
| Brand | B&R |
| Model | 2AO300.6 |
| Category | PLCs & I/O |
| Evidence | B&R ControlSystems Overview Catalog 12/99, p.250 (hosted at rgbautomatyka.pl) |
| Isolation | output-PCC yes; output-output no |
| Module ID | AO300 |
| Resolution | 12 bit |
| Module rack | BP200, BP201, BP210 |
| Output signal | -10 to +10 V V |
| Terminal block | 2TB140.9 (ordered separately) |
| Number of outputs | 16 voltage outputs |
| Power consumption | max. 10 W |
| Max. load per output | +/-10 mA (load >= 1 kOhm) |
