AZBIL C15TVCRD0100 SDC15 Digital Indicating Controller
- Brand
- AZBIL
- Model
- C15TVCRD0100
- GEARWELL SKU
- GWP-000022441
- Category
- Pressure, Flow & Temperature
Key specifications
- Option
- 01: Event relay outputs: 3
- Series
- Single Loop Controller Model C15 (SDC15)
- Mounting
- T: panel mounting type, 48 x 48 mm
- PV input
- RTD input (Pt100/JPt100)
- Power supply
- DC model (24 V AC / 24 to 48 V DC)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL C15TVCRD0100 SDC15 Digital Indicating Controller |
|---|---|
| Brand | AZBIL |
| Model | C15TVCRD0100 |
| Category | Pressure, Flow & Temperature |
| Option | 01: Event relay outputs: 3 |
| Series | Single Loop Controller Model C15 (SDC15) |
| Mounting | T: panel mounting type, 48 x 48 mm |
| PV input | RTD input (Pt100/JPt100) |
| Power supply | DC model (24 V AC / 24 to 48 V DC) |
| Sampling time | 500 ms |
| Control output 1 / 2 | Voltage pulse output (SSR drive) / current output |
| Indication accuracy | ±0.5 % FS ±1 digit |
| Additional processing | None; standards: none |
