AUTONICS TZ4L-22C TZ Series Dual PID Temperature Controller
- Brand
- AUTONICS
- Model
- TZ4L-22C
- GEARWELL SKU
- GWP-000022064
- Category
- Pressure, Flow & Temperature
Key specifications
- Size
- DIN W96xH96mm
- Display
- 9999 (4 digit)
- Evidence
- Autonics TZN/TZ Series Dual PID Auto Tuning Control datasheet, page H-68 ordering information (hosted at instrumart.com)
- Sub output
- Event 1 + Event 2 output
- Power supply
- 24VAC / 24-48VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TZ4L-22C TZ Series Dual PID Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TZ4L-22C |
| Category | Pressure, Flow & Temperature |
| Size | DIN W96xH96mm |
| Display | 9999 (4 digit) |
| Evidence | Autonics TZN/TZ Series Dual PID Auto Tuning Control datasheet, page H-68 ordering information (hosted at instrumart.com) |
| Sub output | Event 1 + Event 2 output |
| Power supply | 24VAC / 24-48VDC |
| Control method | Dual PID auto tuning (high-speed / low-speed response), 2-step auto tuning |
| Control output | Current output (DC4-20mA) |
| Display accuracy | ±0.3% of F.S. value of each input |
| Model-code basis | decoded from the TZ ordering key; no individual model page on autonics.com |
