AUTONICS TK4M-B4RN TK Series Temperature Controller
- Brand
- AUTONICS
- Model
- TK4M-B4RN
- GEARWELL SKU
- GWP-000023134
- Category
- Pressure, Flow & Temperature
Key specifications
- Protection
- IP65 (front panel)
- Option output
- Alarm 1/2, RS485 communication
- Power voltage
- 100-240 VAC 50/60 Hz
- Control method
- ON/OFF, P, PI, PD, PID
- Display method
- 4-digit 7-segment LED
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TK4M-B4RN TK Series Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TK4M-B4RN |
| Category | Pressure, Flow & Temperature |
| Protection | IP65 (front panel) |
| Option output | Alarm 1/2, RS485 communication |
| Power voltage | 100-240 VAC 50/60 Hz |
| Control method | ON/OFF, P, PI, PD, PID |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 50 ms |
| Control output 1 | Relay (250 VAC 3 A) |
| Code as collected | TK4M-B4RN |
| Input specification | Thermocouple K, J, E, T, B, R, S, N, C, G, L, U, Platinel II; RTD DPt100, DPt50, JPt100, Cu100, Cu50, Nickel 120; analog 0-100 mV, 0-5 V, 1-5 V, 0-10 V, 0-20 mA, 4-20 mA |
