AUTONICS TK4L-12RN TK Series PID Temperature Controller
- Brand
- AUTONICS
- Model
- TK4L-12RN
- GEARWELL SKU
- GWP-000021947
- Category
- Pressure, Flow & Temperature
Key specifications
- Option input
- CT, Digital(DI-1/2)
- Option output
- Alarm 1
- Power voltage
- 24VAC 50/60Hz, 24-48VDC
- Control method
- ON/OFF, P, PI, PD, PID
- Display method
- 4-digit 7-segment LED
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TK4L-12RN TK Series PID Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TK4L-12RN |
| Category | Pressure, Flow & Temperature |
| Option input | CT, Digital(DI-1/2) |
| Option output | Alarm 1 |
| Power voltage | 24VAC 50/60Hz, 24-48VDC |
| Control method | ON/OFF, P, PI, PD, PID |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 50 ms |
| Control output 1 | Relay(250VAC 3A) |
| Input specification | Thermocouple: K(CA), J(IC), E(CR), T(CC), B(PR), R(PR), S(PR), N(NN), C(TT), G(TT), L(IC), U(CC), Platinel II; RTD: DPt100Ω, DPt50Ω, JPt100Ω, Cu100Ω, Cu50Ω, Nikel 120Ω; Analog: 0-100mV, 0-5V, 1-5V, 0-10V; 0-20mA, 4-20mA |
| Protection structure | IP65(front panel) |
