AUTONICS M4NN-DA-11 M4NN Compact Digital Panel Meter DC Current
- Brand
- AUTONICS
- Model
- M4NN-DA-11
- GEARWELL SKU
- GWP-000021920
- Category
- Test & Measurement
Key specifications
- Measurement
- DC current
- Power voltage
- 5-24VDC
- Display method
- 4-digit 7-segment LED
- Sampling cycle
- 50 (resolution 1/12,000) ms
- Character height
- 11 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS M4NN-DA-11 M4NN Compact Digital Panel Meter DC Current |
|---|---|
| Brand | AUTONICS |
| Model | M4NN-DA-11 |
| Category | Test & Measurement |
| Measurement | DC current |
| Power voltage | 5-24VDC |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 50 (resolution 1/12,000) ms |
| Character height | 11 mm |
| Max. display range | -1999 to 9999 |
| Input specification | -5-5A, -2-2A, -1-1A, -200-200mA, -100-100mA, -20-20mA, 4-20mA, -10-10mA, -2-2mA |
| Protection structure | IP53 (front part, IEC standard) |
| Main output (comparative value) | NPN open collector (OUT1, GO, OUT2) |
