AUTONICS KRN1000-0841-0S KRN1000 LCD Touchscreen Paperless Recorder
- Brand
- AUTONICS
- Model
- KRN1000-0841-0S
- GEARWELL SKU
- GWP-000021894
- Category
- Test & Measurement
Key specifications
- Option I/O
- 4 alarm relay outputs + 2 digital inputs + 24 VDC transmitter power output
- Power supply
- 100-240 VAC 50/60 Hz
- Communication
- RS422/485 + Ethernet + USB Device
- Sampling cycle
- 1-4 CH: 25/125/250 ms; 5-16 CH: 125/250 ms
- External memory
- SD / USB memory max. 32 GB
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS KRN1000-0841-0S KRN1000 LCD Touchscreen Paperless Recorder |
|---|---|
| Brand | AUTONICS |
| Model | KRN1000-0841-0S |
| Category | Test & Measurement |
| Option I/O | 4 alarm relay outputs + 2 digital inputs + 24 VDC transmitter power output |
| Power supply | 100-240 VAC 50/60 Hz |
| Communication | RS422/485 + Ethernet + USB Device |
| Sampling cycle | 1-4 CH: 25/125/250 ms; 5-16 CH: 125/250 ms |
| External memory | SD / USB memory max. 32 GB |
| Internal memory | approx. 200 MB |
| Universal input | thermocouple, RTD, analog voltage, current (shunt) |
| Front protection | IP50 |
| Recording period | 1 to 3600 s |
| Number of input channels | 8 |
