AUTONICS E40H10-1000-3-N-24 E40H Incremental Rotary Encoder
- Brand
- AUTONICS
- Model
- E40H10-1000-3-N-24
- GEARWELL SKU
- GWP-000021377
- Category
- Encoders & Position
Key specifications
- Resolution
- 1000P/R
- Output phase
- A, B, Z
- Power voltage
- 12-24VDC ±5%(ripple P-P: max. 5%)
- Control output
- NPN open collector
- Connection type
- Radial cable type
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS E40H10-1000-3-N-24 E40H Incremental Rotary Encoder |
|---|---|
| Brand | AUTONICS |
| Model | E40H10-1000-3-N-24 |
| Category | Encoders & Position |
| Resolution | 1000P/R |
| Output phase | A, B, Z |
| Power voltage | 12-24VDC ±5%(ripple P-P: max. 5%) |
| Control output | NPN open collector |
| Connection type | Radial cable type |
| Protection rating | IP50 |
| Shaft inner diameter | Ø10mm |
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
