AUTONICS BW40-24P BW General Purpose Area Sensor 24 Axes
- Brand
- AUTONICS
- Model
- BW40-24P
- GEARWELL SKU
- GWP-000023320
- Category
- Machine Safety & Vision
Key specifications
- Protection
- IP65
- Sensing type
- Through-beam
- Power voltage
- 12-24 VDC +/-10%
- Response time
- Max. 10 ms
- Control output
- PNP open collector
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS BW40-24P BW General Purpose Area Sensor 24 Axes |
|---|---|
| Brand | AUTONICS |
| Model | BW40-24P |
| Category | Machine Safety & Vision |
| Protection | IP65 |
| Sensing type | Through-beam |
| Power voltage | 12-24 VDC +/-10% |
| Response time | Max. 10 ms |
| Control output | PNP open collector |
| Sensing distance | 0.1 to 7 m |
| Optical axis pitch | 40 mm |
| Number of optical axes | 24 |
| Sensing height / total length | 920 / 960 mm |
