Allen-Bradley 2711P-T12W22D9P-BM011 ArmorView Plus 7 12.1-inch Touchscreen HMI
- Brand
- Allen-Bradley
- Model
- 2711PT12W22D9PBM011
- GEARWELL SKU
- GWP-000004106
- Category
- HMIs & Industrial PCs
Key specifications
- Input power
- 24 V DC nominal (18...30 V DC)
- Display size
- 12.1 in widescreen
- Display type
- TFT color
- Product type
- ArmorView Plus 7 operator terminal
- Operator input
- Analog resistive touchscreen
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 2711P-T12W22D9P-BM011 is an ArmorView Plus 7 terminal: a PanelView Plus 7 Performance 12.1-in. widescreen touch module (1280 x 800 WXGA, 24V DC, two Ethernet ports) in an enclosure for arm, machine or pedestal mounting. This version ships with an arm mount adapter and a button plate with a twist-to-release illuminated E-stop, 3 momentary push buttons and a three-position selector switch. The buttons and selectors are wired to an included 1732E ArmorBlock dual-port EtherNet/IP I/O module; the E-stop circuit is independent. An optional VESA kit (2711P-RVESA01) replaces the arm adapter with an I/O plate, and handles and stack lights can be added as accessories.
Technical reference
| Product name | Allen-Bradley 2711P-T12W22D9P-BM011 ArmorView Plus 7 12.1-inch Touchscreen HMI |
|---|---|
| Brand | Allen-Bradley |
| Model | 2711PT12W22D9PBM011 |
| Category | HMIs & Industrial PCs |
| Input power | 24 V DC nominal (18...30 V DC) |
| Display size | 12.1 in widescreen |
| Display type | TFT color |
| Product type | ArmorView Plus 7 operator terminal |
| Operator input | Analog resistive touchscreen |
| Network interface | 10/100 Mbps Ethernet with Device Level Ring (DLR) support |
| Maximum power consumption | 37 W maximum |
| Display resolution | 1280 x 800 WXGA |
| Catalog Ethernet I/O configuration | 1732E-8CFGM8R module with eight configurable input/output ports |
| Catalog button configuration | E-stop; 3 momentary push buttons; 3-position selector |
| Memory and operating system by series | Series A: 512 MB RAM, 512 MB storage, Windows CE 6.0; Series B: 4 GB RAM, 19.87 GB storage, Windows 10 IoT Core |
| Operating temperature | 0...50 °C ambient; 45 °C maximum with optional VESA I/O-plate kit |
| Official catalog number | 2711P-T12W22D9P-BM011 |
