Allen-Bradley 20G21ND052JA0NNNNN PowerFlex 755TS 480 V AC 40 hp AC Drive

Key specifications

Operator interface: No factory-fitted HIM
Drive frame: 4
Nominal input voltage: 480 V AC, three-phase
Protection and cooling: Standard corrosive-gas protection; forced-air cooling
Rated motor output: 52 A continuous, 40 hp normal duty; 30 hp heavy duty

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Allen-Bradley 20G21ND052JA0NNNNN PowerFlex 755TS 480 V AC 40 hp AC Drive
Brand	Allen-Bradley
Model	20G21ND052JA0NNNNN
Category	Variable Frequency Drives
Operator interface	No factory-fitted HIM
Drive frame	4
Nominal input voltage	480 V AC, three-phase
Protection and cooling	Standard corrosive-gas protection; forced-air cooling
Rated motor output	52 A continuous, 40 hp normal duty; 30 hp heavy duty
Braking hardware	Internal braking transistor fitted; braking resistor not included
Built-in communication	Dual embedded EtherNet/IP ports
Configured enclosure	IP20, NEMA/UL Open Type
EMC filtering and CM jumper	EMC filter fitted; CM jumper installed
