Allen-Bradley 20G1ANC205JN0NNNNN Industrial Electronic Component

Allen-Bradley 20G1ANC205JN0NNNNN PowerFlex 755 110 kW 400 V AC VFD

Model
20G1ANC205JN0NNNNN
GEARWELL SKU
GWP-000001133
Category
Industrial Automation Parts

Key specifications

Enclosure
IP00, NEMA/UL Type Open
Product type
PowerFlex 755 variable-frequency AC drive
AC input voltage
400 V AC
Normal-duty output current
205 A
Dynamic braking
No internal braking transistor
Request a QuoteWhatsApp

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

← Back to products

Product overview

The Allen-Bradley 20G1ANC205JN0NNNNN is a PowerFlex 755 AC drive for the 400 V AC / 540 V DC class in frame 6, built as an IP00, NEMA/UL Type Open wall-mount chassis with AC input with precharge and no DC terminals. Rockwell rates it at 205 A and 110 kW for normal duty and 170 A and 90 kW for heavy duty. This version has filtering with the common mode capacitor jumper installed and no internal dynamic braking transistor. Wall-mount frames 1…7 include a DC link choke, and frame 6…7 Open Type drives can be converted to IP20, NEMA/UL Type 1 with the 20-750-NEMA1-Fx kit. The PowerFlex 755 is Rockwell's 750-Series drive for maximum flexibility and performance up to 2000 Hp and 1500 kW, with a built-in Ethernet port, slot-based option cards, DeviceLogix embedded control and a choice of safety options.

Technical reference

Product nameAllen-Bradley 20G1ANC205JN0NNNNN PowerFlex 755 110 kW 400 V AC VFD
BrandAllen-Bradley
Model20G1ANC205JN0NNNNN
CategoryIndustrial Automation Parts
EnclosureIP00, NEMA/UL Type Open
Product typePowerFlex 755 variable-frequency AC drive
AC input voltage400 V AC
Normal-duty output current205 A
Dynamic brakingNo internal braking transistor
Heavy-duty motor power90 kW
Lifecycle statusActive mature
Normal-duty motor power110 kW
Drive configurationThe Allen-Bradley 20G1ANC205JN0NNNNN is a PowerFlex 755 variable-frequency drive for AC motor control. Rated at 110 kW normal duty (90 kW heavy duty), with 205 A continuous normal-duty output. AC input with precharge, without DC terminals, rated 400 V AC three-phase input. Enclosure: IP00, NEMA/UL Type Open. Frame 6. No internal braking transistor. EMC filter; common-mode jumper installed by default. Operator interface: No door-mounted HIM. Embedded EtherNet/IP interface. Standard protection; forced-air cooling.
