Allen-Bradley 20G1ABF460JN0NNNNN PowerFlex 755 450 kW 690 V AC VFD
- Brand
- Allen-Bradley
- Model
- 20G1ABF460JN0NNNNN
- GEARWELL SKU
- GWP-000003399
- Category
- Industrial Automation Parts
Key specifications
- Enclosure
- IP20, NEMA/UL Type 1 MCC cabinet, 600 mm depth
- Product family
- PowerFlex 755
- Product type
- PowerFlex 755 variable-frequency AC drive
- AC input voltage
- 690 V AC
- Normal-duty output current
- 460 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 20G1ABF460JN0NNNNN is a PowerFlex 755 AC drive for the 690 V AC / 932 V DC class in frame 8, built as an IP20, NEMA/UL Type 1 floor-mount cabinet 600 mm deep (standard cabinet color RAL 7032) with AC input with precharge and no DC terminals. Rockwell rates it at 500 A and 500 kW for light duty, 460 A and 450 kW for normal duty and 375 A and 375 kW for heavy duty. This version has filtering with the common mode capacitor jumper installed, no internal dynamic braking transistor and no door-mounted HIM. Floor-mount frames 8…10 include a DC link choke, integrated AC line fuses and a roll-out design; Rockwell requires a roll-out cart to install the drive. The PowerFlex 755 is Rockwell's 750-Series drive for maximum flexibility and performance up to 2000 Hp and 1500 kW, with a built-in Ethernet port, slot-based option cards, DeviceLogix embedded control and a choice of safety options.
Technical reference
| Product name | Allen-Bradley 20G1ABF460JN0NNNNN PowerFlex 755 450 kW 690 V AC VFD |
|---|---|
| Brand | Allen-Bradley |
| Model | 20G1ABF460JN0NNNNN |
| Category | Industrial Automation Parts |
| Enclosure | IP20, NEMA/UL Type 1 MCC cabinet, 600 mm depth |
| Product family | PowerFlex 755 |
| Product type | PowerFlex 755 variable-frequency AC drive |
| AC input voltage | 690 V AC |
| Normal-duty output current | 460 A |
| Dynamic braking | No internal braking transistor |
| Heavy-duty motor power | 375 kW |
| Lifecycle status | Active |
| Normal-duty motor power | 450 kW |
| Drive configuration | The Allen-Bradley 20G1ABF460JN0NNNNN is a PowerFlex 755 variable-frequency drive for AC motor control. Rated at 450 kW normal duty (375 kW heavy duty), with 460 A continuous normal-duty output. AC input with precharge, without DC terminals, rated 690 V AC three-phase input. Enclosure: IP20, NEMA/UL Type 1 MCC cabinet, 600 mm depth. Frame 8. No internal braking transistor. EMC filter; common-mode jumper installed by default. Operator interface: No door-mounted HIM. Light-duty motor rating: 500 kW. Embedded EtherNet/IP interface. Standard protection; forced-air cooling. |
| EMC filter and common-mode jumper | EMC filter; common-mode jumper installed by default |
