Allen-Bradley 2080-LC70-24QWB Micro870 24-Point EtherNet/IP PLC
- Brand
- Allen-Bradley
- Model
- 2080-LC70-24QWB
- GEARWELL SKU
- GWP-000003419
- Category
- PLCs & I/O
Key specifications
- Depth
- 80mm
- Memory
- 280 KB
- Communication and programming ports
- RJ-45 Ethernet; non-isolated RS-232/RS-485 combo serial; USB Type B programming port.
- Digital input signal
- 24 V DC/AC.
- Controller supply (nominal)
- 24 V DC; separate from input signal voltage.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 2080-LC70-24QWB is a Micro870 24-point controller with 14 inputs for 24V DC/V AC and 10 relay outputs, with 4 embedded high-speed counters. It has an embedded 10/100 Base-T Ethernet port, USB programming and RS-232/RS-485 serial ports, 3 plug-in slots and support for up to eight expansion I/O modules, with about 20K program steps and 40 KB of data. It takes a class 2 24V DC supply, such as the optional Micro800 power supply.
Technical reference
| Product name | Allen-Bradley 2080-LC70-24QWB Micro870 24-Point EtherNet/IP PLC |
|---|---|
| Brand | Allen-Bradley |
| Model | 2080-LC70-24QWB |
| Category | PLCs & I/O |
| Depth | 80mm |
| Memory | 280 KB |
| Communication and programming ports | RJ-45 Ethernet; non-isolated RS-232/RS-485 combo serial; USB Type B programming port. |
| Digital input signal | 24 V DC/AC. |
| Controller supply (nominal) | 24 V DC; separate from input signal voltage. |
| Communication | Modbus, ASCII, CIP |
| Maximum expanded I/O | Up to 304 I/O points with suitable plug-in and expansion modules; 24 points are built in. |
| Output Signal | Relay |
| Embedded Ethernet port | 10/100 Base-T with RJ-45 connector. |
| Plug-in module capacity | Up to 3 Micro800 plug-in modules. |
| Built-in I/O | 14 inputs; 10 outputs. |
| Expansion I/O module capacity | Up to 8 expansion I/O modules; subject to module compatibility and system power limits. |
