Allen-Bradley 1606XLS480E3 Industrial Power Supply
- Brand
- Allen-Bradley
- Model
- 1606XLS480E3
- GEARWELL SKU
- GWP-000002125
- Category
- Power Supplies
Key specifications
- Input Type
- Multi-Phase input
- Input Voltage
- 3 x 380...480V AC
- Output Voltage
- 24...28V DC
- Connection Terminals
- Spring-clamp Terminals
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 1606-XLS480E-3 is a 1606-XLS Performance DIN-rail power supply for three-phase 380…480V AC input, with a 24V DC output adjustable to 28V, 20 A and 480 W, plus a 50% power reserve. It is typically 95.0% efficient, has spring terminals and a DC OK relay contact, and is rated for -25…+70 °C with derating above 60 °C. It measures 65 x 124 x 127 mm (W x H x D) and weighs 870 g.
Technical reference
| Product name | Allen-Bradley 1606XLS480E3 Industrial Power Supply |
|---|---|
| Brand | Allen-Bradley |
| Model | 1606XLS480E3 |
| Category | Power Supplies |
| Input Type | Multi-Phase input |
| Input Voltage | 3 x 380...480V AC |
| Output Voltage | 24...28V DC |
| Connection Terminals | Spring-clamp Terminals |
