Advantech PCI-1758UDO PCI-1758 128-ch Isolated Digital Output PCI Card
- Brand
- Advantech
- Model
- PCI-1758UDO
- GEARWELL SKU
- GWP-000023375
- Category
- PLCs & I/O
Key specifications
- Bus type
- Universal PCI V2.2
- Output type
- Sink (NPN)
- Sink current
- 200 mA/ch @ 25 °C, 150 mA/ch @ 60 °C
- Ordering code
- PCI-1758UDO-BE
- I/O connectors
- 2 x mini-SCSI HDRA-E100 female
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Advantech PCI-1758UDO PCI-1758 128-ch Isolated Digital Output PCI Card |
|---|---|
| Brand | Advantech |
| Model | PCI-1758UDO |
| Category | PLCs & I/O |
| Bus type | Universal PCI V2.2 |
| Output type | Sink (NPN) |
| Sink current | 200 mA/ch @ 25 °C, 150 mA/ch @ 60 °C |
| Ordering code | PCI-1758UDO-BE |
| I/O connectors | 2 x mini-SCSI HDRA-E100 female |
| Output voltage | 5~40 VDC |
| Isolation protection | 2500 VDC |
| Operating temperature | 0~60 °C |
| Isolated digital outputs | 128 |
