Actuonix PQ12-63-12-P PQ12-P Micro Linear Actuator with Feedback
- Brand
- Actuonix
- Model
- PQ12-63-12-P
- GEARWELL SKU
- GWP-000012168
- Category
- Cylinders & Actuators
Key specifications
- Weight
- 21 g
- Control
- P (potentiometer feedback)
- Voltage
- 12 VDC
- Gear ratio
- 63:1
- Maximum load
- 45 N
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Actuonix PQ12-63-12-P PQ12-P Micro Linear Actuator with Feedback |
|---|---|
| Brand | Actuonix |
| Model | PQ12-63-12-P |
| Category | Cylinders & Actuators |
| Weight | 21 g |
| Control | P (potentiometer feedback) |
| Voltage | 12 VDC |
| Gear ratio | 63:1 |
| Maximum load | 45 N |
| No load speed | 15 mm/s |
| Stroke length | 20 mm |
| Backdrive force | 25 N |
| Closed hole to hole | 42 mm |
| Peak efficiency load | 12 N |
