ABB TU838 ABB AC 800M controller / S800 I/O Extended MTU 50 V
- Brand
- ABB
- Model
- TU838
- GEARWELL SKU
- GWP-000014422
- Category
- PLCs & I/O
Key specifications
- Rated voltage
- 50 V
- Signal terminals
- 16
- Type designation
- TU838
- Product net width
- 58.5 mm
- Product net height
- 170 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB TU838 is an extended module termination unit (MTU) for S800 I/O in 50 V applications, with screw terminals, power distribution and fuse. S800 I/O runs on 24 V d.c. (19.2 - 30 V), is rated IP20 and +5 to +55 °C operating, and takes up to 24 I/O modules per I/O station.
Technical reference
| Product name | ABB TU838 ABB AC 800M controller / S800 I/O Extended MTU 50 V |
|---|---|
| Brand | ABB |
| Model | TU838 |
| Category | PLCs & I/O |
| Rated voltage | 50 V |
| Signal terminals | 16 |
| Type designation | TU838 |
| Product net width | 58.5 mm |
| Product net height | 170 mm |
| Product net weight | 0.375 kg |
| Product net depth/length | 64 mm |
| Fused transducer power outlets | 2x4 |
