ABB TB541-ETH AC500 Terminal Base
- Brand
- ABB
- Model
- TB541-ETH
- GEARWELL SKU
- GWP-000003969
- Category
- Industrial Automation Parts
Key specifications
- Direct I/O expansion
- Up to 10 expansion modules
- Product type
- AC500 CPU/communication-module terminal base
- Plug-in communication-module slots
- 4
- Listed weight
- 0.215 kg
- Identified model
- TB541-ETH
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB TB541-ETH is the AC500 CPU terminal base (order code 1SAP114100R0270) with 4 coupler slots and an Ethernet RJ45 connection for the coupler integrated in the CPU. It also provides the I/O interface for up to 10 expansion modules, a FieldBusPlug slave interface, COM1 on a 9-pole pluggable terminal block and COM2 on a 9-pole Sub-D; weight is 0.215 kg.
Technical reference
| Product name | ABB TB541-ETH AC500 Terminal Base |
|---|---|
| Brand | ABB |
| Model | TB541-ETH |
| Category | Industrial Automation Parts |
| Direct I/O expansion | Up to 10 expansion modules |
| Product type | AC500 CPU/communication-module terminal base |
| Plug-in communication-module slots | 4 |
| Listed weight | 0.215 kg |
| Identified model | TB541-ETH |
| Integrated CPU coupler connection | Ethernet RJ45 |
| Manufacturer order code | 1SAP114100R0270 |
