ABB SPAM 150 C SPACOM Motor protection relay (order no. RS 641 014-AA)
- Brand
- ABB
- Model
- SPAM 150 C
- GEARWELL SKU
- GWP-000029532
- Category
- Relays & Controllers
Key specifications
- Trip contact
- NO
- Rated frequency
- 50 Hz
- Rated current In
- 1 A / 5 A (terminal selectable)
- Auxiliary supply voltage
- 80...265 V ac/dc
- Output contact rated voltage
- 250 V ac/dc
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB SPAM 150 C SPACOM Motor protection relay (order no. RS 641 014-AA) |
|---|---|
| Brand | ABB |
| Model | SPAM 150 C |
| Category | Relays & Controllers |
| Trip contact | NO |
| Rated frequency | 50 Hz |
| Rated current In | 1 A / 5 A (terminal selectable) |
| Auxiliary supply voltage | 80...265 V ac/dc |
| Output contact rated voltage | 250 V ac/dc |
| Thermal withstand, continuous | 4 A (1 A input) / 20 A (5 A input) |
| Phase current monitoring range | 0...63 x In |
