ABB S201M-C25 S200M Miniature Circuit Breaker 1P C25A

Product overview

The ABB S201M-C25 is a 1-pole System pro M compact S200M miniature circuit breaker with C tripping characteristic and 25 A rated current, ABB order code 2CDS271001R0254. It has a rated short-circuit capacity Icn of 10 kA to IEC/EN 60898-1 and is also listed to IEC/EN 60947-2. ABB specifies the C characteristic for protecting circuits against overload and short circuit with resistive and inductive loads with low inrush current, in residential, commercial and industrial installations. The S200 range has a red/green contact position indicator and finger-proof (IP20) twin terminals for cables up to 35 mm².
