ABB IMHSS03 Symphony / Harmony rack I/O (INFI 90) Hydraulic servo module

Key specifications

LVDT inputs: 2 LVDT secondary inputs (4 analog inputs)
Digital inputs: 3 optically isolated
Operating voltage: +5 V DC ±5 % at 576 mA; +24 V DC ±10 % at 335 mA (typical)
Ambient temperature: 0 to 70 °C
Servo valve outputs: 2 redundant (4 analog outputs), up to ±64 mA

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	ABB IMHSS03 Symphony / Harmony rack I/O (INFI 90) Hydraulic servo module
Brand	ABB
Model	IMHSS03
Category	PLCs & I/O
LVDT inputs	2 LVDT secondary inputs (4 analog inputs)
Digital inputs	3 optically isolated
Operating voltage	+5 V DC ±5 % at 576 mA; +24 V DC ±10 % at 335 mA (typical)
Ambient temperature	0 to 70 °C
Servo valve outputs	2 redundant (4 analog outputs), up to ±64 mA
I/H converter output	4-20 mA at 300 ohm max
LVDT excitation frequency	400 Hz to 15 kHz
