ABB CI854 AC 800M PROFIBUS DP-V1 communication interface module
- Brand
- ABB
- Model
- CI854
- GEARWELL SKU
- GWP-000029091
- Category
- Industrial Communication
Key specifications
- Protocol
- PROFIBUS DP (DP-V1 master)
- Connectors
- Two DB9 female on TP854 (line redundancy)
- Power dissipation
- 4.6 typical W
- Protection rating
- IP20
- Communication speed
- 9.6 kbit/s to 12 Mbit/s
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB CI854 AC 800M PROFIBUS DP-V1 communication interface module |
|---|---|
| Brand | ABB |
| Model | CI854 |
| Category | Industrial Communication |
| Protocol | PROFIBUS DP (DP-V1 master) |
| Connectors | Two DB9 female on TP854 (line redundancy) |
| Power dissipation | 4.6 typical W |
| Protection rating | IP20 |
| Communication speed | 9.6 kbit/s to 12 Mbit/s |
| Dimensions (W x H x D) | 59 x 185 x 127.5 mm |
| Current consumption (CEX-Bus 24 V DC) | 190 typical (240 max) mA |
