ABB C150 COMMANDER 150 1/8 DIN universal process indicator
- Brand
- ABB
- Model
- C150
- GEARWELL SKU
- GWP-000029039
- Category
- Controls & Thermostats
Key specifications
- Display
- 1 x 6-digit 7-segment LED, 14 mm
- Relay output
- 1 SPDT, 5 A at 115/230 V AC
- Analog inputs
- 1, universal (THC, RTD, mV, mA, V)
- Retransmission
- 4-20 mA
- Size (W x H x D)
- 96 x 48 x 125 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB C150 COMMANDER 150 1/8 DIN universal process indicator |
|---|---|
| Brand | ABB |
| Model | C150 |
| Category | Controls & Thermostats |
| Display | 1 x 6-digit 7-segment LED, 14 mm |
| Relay output | 1 SPDT, 5 A at 115/230 V AC |
| Analog inputs | 1, universal (THC, RTD, mV, mA, V) |
| Retransmission | 4-20 mA |
| Size (W x H x D) | 96 x 48 x 125 mm |
| Supply voltage | 85-265 V AC 50/60 Hz (24 V DC option) |
| Front protection | IP65 |
| Power consumption | <6 VA |
